| Dimensions (D x L) (mm) | 91 x 73 x 37 / 3.6 x 2.9 x 1.5 |
| Electromagnetic Compatibility | FCC Part15 SubPartB class B EU: EMC directive AS/NZS VCCI class B CU TR 020 ICES-003 GB: Electromagnetic Compatibility Regulations |
| Laser Classification | IEC60825-1: Class 1M/Laser Product FDA/21 CFR Part 1040.10: Class I Laser Product |
| Eye Relief (mm) | 16.7 |
| Exit Pupil (mm) | 3.3 |
| Actual Field of View (°) | 6 |
| Finder: Effective Objective Diameter (mm) | 20 |
| Accuracy | ±1m (shorter than 100m) ±2m (100m and over) |
| Distance Display (Increment) | 1m |
| Measurement Range | 5~730m |
| Power Source | CR2 lithium battery × 1 (DC 3V) Automatic power shut-off (after approx. 8 sec. unoperated) |
| Weight (g) (Body Only)* | 130 / 4.6 |
| Magnification (x) | 6x |
| Diopter Adjustment | ±4 m-1 |
| Beam Divergence (MRAD) | Vertical: 2.5 Horizontal: 0.2 |
| Operating Temperature | -10 — +50/14 — 122 |
| Operating Humidity | 80 or less (without dew condensation) |
| Output (W) | 15.2 |
| Pulse Duration (NS) | 20 |
| Battery Life | Approx. 10 000 times (at approx. 20°C) *This figure may differ according to conditions such as temperature and other factors. Use only as a guide |
| Guide for Maximum Measurement Distance to a Flagstick* | 270m |
| Waterproof Structure | 905 |
