BlackVue DR770X-1CH II features Full HD Sony STARVIS™ image sensor for best image quality under any light.
Also included are GPS logger, built-in Wi-Fi, Cloud connectivity, impact and motion detection.
Full HD Cloud Dashcams
Powered by Sony STARVIS Sensors
Native Parking Mode
Let your BLACKVUE watch over your vehicle 24/7
What's Included?
• Front Camera
• Hardwiring Power Cable
• USB-C Power Cable
• USB-C 12V Adapter
• MicroSD Card
• Double-sided tape for the mounting bracket
• Pry tool / Trim Remover
• Cable clips (3 EA)
• Alcohol Pad
Specifications
Model Name DR770X-1CH II
Channel
1CH (upgradable to 2CH)
Highlights
Full HD, Cloud, Wi-Fi, GPS, Sony Sensor, External LTE Module
Product Dimensions
Black /length 135.0mm x Width 101.0mm x Height 37.5mm / 209g
Memory Support
microSD card up to 1TB
Recording Modes
Normal recording, Event recording (when impact is detected in normal and parking mode), Manual recording and Parking recording (when motion is detected).
* When using Hardwiring Power Cable, ACC+ will trigger parking mode. When using other methods, G-sensor will trigger parking mode.
Parking Mode
YES (hardwiring cable included)
Parking Mode Event Voice Notifications
YES
Imaging Sensor
Sony STARVIS™ CMOS Sensor (Approx. 2.1 M Pixel)
Viewing Angle
Diagonal 139°, Horizontal 116°, Vertical 62°
Resolution Frame Rate
Full HD @60fps
* Frame rate may vary during Wi-Fi streaming
Video Codec
H.264 (AVC)
Image Quality and Bitrate Front/Rear
Highest (Extreme): 25 Mbps
Highest: 12 Mbps
High: 10 Mbps
Normal: 8 Mbps
Format Free
YES (Adaptive)
Event File Overwrite Protection
YES (up to 50)
SD Card Failure Alert
YES
Scheduled Reboot
YES
Video File Extension
MP4
Wi-Fi
Built-in (802.11 b.g.n)
Cloud Compatible
YES
GPS
Built-in (Dual Band : GPS, GLONASS)
Specifications
Microphone
Built-in
Speaker
Built-in
Impact Sensor
3-Axis Acceleration Sensor
LED Indicators
Recording LED, GPS LED, B/W/L (Bluetooth/Wi-Fi/LTE) LED, Front Security LED
Button
Format Button: Press and hold format button for 5 seconds, and after a beep, release the button. Then, press again and hold for 5 seconds and release the button after a beep to format the microSD card.
Touch Sensor: Pressing the touch sensor triggers manual recording depending on the firmware settings.
Operation Temperature
-20 °C − 80 °C (-4 °F − 176 °F)
Storage Temperature
-20 °C − 80 °C (-4 °F − 176 °F )
High Temp Cut Off
Approx. 80 °C (176 °F)
Backup Battery
Built-in supercapacitor
Input Power
DC 12V-24V (DC Plug (Ø3.5 x Ø1.1)) to Wires (Black: GND / Yellow: B+ / Red: ACC)
Power Consumption Hour
Normal Mode (GPS On/1CH): Avg. 240mA / 12V
Parking Mode (GPS Off/1CH): Avg. 190mA / 12V
* Actual power consumption may vary depending on use conditions and environment
Certifications
FCC, ISED, CE, UKCA, RCM, RoHS, Telec, WEEE, KC
Software
BlackVue Viewer
* Windows 7 or higher, Mac Sierra OS X (10.12) or higher
BlackVue Web Viewer
* Chrome 71 or higher, Safari 13.0 or higher
Application
BlackVue Application
* Android 8.0 or higher, iOS 13.0 or higher
Others
Adaptive Format-Free File Management System
Bluetooth Built-in (V2.1+EDR/4.2)
LTE External (optional)
BlackVue DR770X Box-3CH Pro features front, rear and interior protection for your vehicle, powered by Sony image sensors for best image quality under any light. Also included are GPS logger, Wireless Button, built-in Wi-Fi, Cloud connectivity and built-in voltage monitoring for Parking Mode.
What's Included?
• Main Unit
• Front Camera
• Rear Camera
• Rear Infrared Camera
• SOS Button
• Main unit cigarette lighter power cable (4.5M)
• Main unit hard wiring power cable (4.5m)
• Camera connection cable (6m, 3EA)
• Micro SD with Card Reader
• Quick start Guide
• Mounting Tape and Main unit key
Specifications
Model Name DR770X Box-3CH Pro
Channel
3CH
Highlights
Full HD + Full HD + Full HD (Front + Rear + Interior), Cloud, Wi-Fi, Triple Sony Sensors, External GPS and LTE Module
Product Dimensions
Main unit : Black / Length 135.0 mm x Width 101.0 mm x Height 37.5 mm / 225 g
Front : Black / Length 77.5 mm x Width 34 mm x Height 49.5 mm / 61 g
Rear : Black / Length 69.5 mm x Width 32.0 mm x Height 48.3 mm / 46 g
Interior IR : Black / Length 69.5 mm x Width 32.0 mm x Height 48.3 mm / 47 g
Wireless Button : Black / Length 45.2 mm x Width 42.0 mm x Height 14.5 mm / 23 g
Rear Camera Connection
Coaxial cable
Memory Support
microSD card up to 512GB
Recording Modes
Normal recording, Event recording (when the impact is detected in normal and parking mode),
Manual recording and Parking recording (when motion is detected) * When using Hardwiring Power Cable,
ACC+ will trigger parking mode. When using other methods, G-sensor will trigger parking mode.
Imaging Sensor
Front: STARVIS CMOS Sensor (Approx. 2.1 M Pixel)
Rear: STARVIS CMOS Sensor (Approx. 2.1 M Pixel)
Interior IR: STARVIS CMOS Sensor (Approx. 2.1 M Pixel)
Viewing Angle
Front(FC1) : Diagonal 139°, Horizontal 116°, Vertical 61°
Rear(RC1-C) : Diagonal 139°, Horizontal 116°, Vertical 61°
Interior IR(RC1-IR-C) : Diagonal 180°, Horizontal 150°, Vertical 93°
Resolution Frame Rate
Front / Rear / Interior IR
Full HD (1920×1080) @ 60 fps – Full HD (1920×1080) @ 30 fps- Full HD (1920×1080) @ 30 fps
*Frame rate may vary during Wi-Fi streaming.
Video Codec
H.264 (AVC)
Image Quality and Bitrate Front/Rear
Front / Rear / Interior
Extreme: 16 + 10 + 10 Mbps
Highest: 12 + 10 + 10 Mbps
High: 10 + 8 + 8 Mbps
Normal: 8 + 6 + 6 Mbps
Format Free
YES (Adaptive)
Event File Overwrite Protection
YES (up to 51)
Specifications
SD Card Failure Alert YES
Scheduled Reboot YES
Video File Extension MP4
Wi-Fi Built-in (802.11 b.g.n)
Cloud Compatible YES
GPS External (Dual Band : GPS, GLONASS)
Microphone Built-in
Speaker Built-in
Impact Sensor 3-Axis Acceleration Sensor
LED Indicators Main unit: Recording LED, GPS LED, B/W/L (Bluetooth/Wi-Fi/LTE) LED, Front Security LED
Front: Front & Rear Security LED
Rear: Front & Rear Security LED
Interior IR: Front & Rear Security LED
EB-1: Operating / Battery low voltage LED
Rear Camera IR Illumination Interior IR: 940nm (2 Infrared (IR) LEDs)
Button EB-1 button : Press the button – manual recording.
Operation Temperature -20°C – 70°C (-4°F – 158°F )
Storage Temperature -20°C – 80°C (-4°F – 176°F )
High Temp Cut Off Approx. 75 °C (167 °F)
Backup Battery Built-in supercapacitor
Input Power DC 12V-24V (3 pole DC Plug(Ø3.5d x Ø1.1) to Wires (Black: GND / Yellow: B+ / Red: ACC)
Power Consumption Hour Normal Mode (GPS On/3CH) : Avg. 750mA/12V
Parking Mode (GPS Off/3CH) : Avg. 600mA/12V
* Approx.40mA increase in current when Interior Camera IR LEDs are ON.
* Actual power consumption may vary depending on use conditions and environment.
Certifications Front: FCC, CE, Telec, IC, UKCA, RoHS, WEEE, RCM
Rear: FCC, IC CE, UKCA, RCM, RoHS, WEEE, KC
Software BLACKVUE Viewer
* Windows 7 or higher, Mac Sierra OS X (10.12) or higher
BLACKVUE Web Viewer
* Chrome 71 or higher, Safari 13.0 or higher
Application BLACKVUE Application
* Android 8.0 or higher, iOS 13.0 or higher
Others Adaptive Format Free File Management System
Bluetooth Built-in (V2.1+EDR/4.2)
LTE External (optional)
Imaging Excellence Since 2007
DR970X Plus II blends top-of-the-line components with BlackVue's imaging know how and expert tuning.
4K STARVIS 2 HDR Clarity
Series II brings improved dash cam performance with advanced HDR technology. It is designed to provide clear and well-balanced video recordings in both bright sunlight and low-light situations.
Hassle-Free Installation
1. Mount the camera
2. Plug the power cable
3. Start driving
Install and forget: With the included USB-C cable and 12V auxiliary adapter
Hardwiring Cable Included: Connect to your car’s fuse panel to enable Parking Mode
Simple and Secure
With Seamless Pairing, connecting to your dash cam with the BlackVue App is easy as 1, 2, 3.
1. Tap + Camera
2. Select your BlackVue in the list
3. Tap the touch sensor
That’s it! Your camera is added a ready for use.
All Features At Your Fingertips
The BlackVue App is designed with simplicity and ease of use in mind. No convoluted menus. Access all the key features from the main screen.
Comprehensive Event Detection
Detects and records driving impacts, parking impacts, sudden acceleration, hard braking, sharp turns, and overspeeding using the built-in G-Sensor and GPS.
Always Get the Full Picture!
With buffered recording, Event clips always include the action that led to the triggering event.
24/7 Protection for your vehicle
With the Parking Mode Accessories
What's included?
• Front Camera
• Hardwiring Power Cable
• USB-C Power Cable
• USB-C 12V Adapter
• MicroSD Card
• Double-sided tape for the mounting bracket
• Pry tool / Trim Remover
• Cable clips (3 EA)
• Alcohol Pad
The All-Inclusive Dash Cam
Redefined Clarity with Dual HDR
ELITE 8 offers improved dash cam performance with advanced HDR technology. It is designed to provide clear and well-balanced video recordings in both bright sunlight and low-light situations.
18 Years of BlackVue Imaging Mastery
ELITE 8 redefines dash cam clarity by combining the best components with BlackVue’s expert image tuning mastery acquired over 18 years of experience.
24/7 Protection for your vehicle With the Parking Mode Accessories
Up to Over 12 Months of Protection!
In Power Saving Mode, the dash cam minimizes power consumption by going into standby, then wakes up on impact and goes back to standby mode after 1 min recording. Provides several weeks of protection when hardwired to a car with a healthy battery and up to several months of protection when paired with BlackVue Ultra Battery (B-130A).
Comprehensive Event Detection
Detects and records driving impacts, parking impacts, sudden acceleration, hard braking, sharp turns, and overspeeding using the built-in G-Sensor and GPS.
Always Get the Full Picture!
With buffered recording, Event clips always include the action that led to the triggering event.
Your Most Important Clips are Protected
Like every dash cam, ELITE constantly records in a loop. When the microSD card storage is full, older clips are automatically overwritten by newer footage.
With its Event File Protection function, ELITE ensures that critical footage is not overwritten by normal driving clips.
Hassle-Free Installation
1. Mount the front and rear cams
2. Plug the power and video cables
3. Start driving
Simple and Secure
With Seamless Pairing, connecting to your dash cam with the BlackVue App is easy as 1, 2, 3.
All Features At Your Fingertips
The BlackVue App is designed with simplicity and ease of use in mind.
No convoluted menus. Access all the key features from the main screen.
What's Included:
• Front Camera
• USB-C Power Cable
• USB-C 12V Adapter
• MicroSD Card
• Double-sided tape for the mounting bracket
• Pry tool/ Trim Remover
• Cable clips (3 EA)
• Alcohol Pad
18 Years of BlackVue Imaging Mastery
ELITE 8 redefines dash cam clarity by combining the best components with BlackVue’s expert image tuning mastery acquired over 18 years of experience.
Redefined Clarity with Dual HDR
ELITE 8 offers improved dash cam performance with advanced HDR technology. It is designed to provide clear and well-balanced video recordings in both bright sunlight and low-light situations.
24/7 Protection for your vehicle
With the Parking Mode Accessories
Up to Over 12 Months of Protection!
In Power Saving Mode, the dash cam minimizes power consumption by going into standby, then wakes up on impact and goes back to standby mode after 1 min recording.
Provides several weeks of protection when hardwired to a car with a healthy battery and up to several months of protection when paired with BlackVue Ultra Battery (B-130A).
Comprehensive Event Detection
Detects and records driving impacts, parking impacts, sudden acceleration, hard braking, sharp turns, and overspeeding using the built-in G-Sensor and GPS.
Always Get the Full Picture!
With buffered recording, Event clips always include the action that led to the triggering event.
Your Most Important Clips are Protected
Like every dash cam, ELITE constantly records in a loop. When the microSD card storage is full, older clips are automatically overwritten by newer footage.
With its Event File Protection function, ELITE ensures that critical footage is not overwritten by normal driving clips.
Hassle-Free Installation
1. Mount the front and rear cams
2. Plug the power and video cables
3. Start driving
Simple and Secure
With Seamless Pairing, connecting to your dash cam with the BlackVue App is easy as 1, 2, 3.
All Features At Your Fingertips
The BlackVue App is designed with simplicity and ease of use in mind.
No convoluted menus. Access all the key features from the main screen.
Stealthy, Reliable and Functional
BlackVue ELITE 8 is designed with stealth, durability and functionality in mind.
What's Included:
• Front Camera
• Rear Camera
• USB-C Cable
• USB-C 12V Adapter
• Rear camera connection cable
• MicroSD Card
• Double-sided tape for the mounting brackets
• Pry tool / Trim Remover
• Cable clips(5 EA)
• Alcohol Pad
The Blackvue ERC1-C External Dash Cam is a Full HD accessory camera that can be used with the Blackvue DR770X Range of cameras including the Box Pro. It features a wide field of view and can be used to capture footage from the rear, side, or interior of your vehicle. The ERC1-C is also weatherproof and can be used in all conditions.
If you are looking for a versatile and durable external dash cam for your Blackvue DR770X Box Pro, the Blackvue ERC1-C is a great option.
1. External Rear Camera for DR770X / DR770X Box / DR770X Box Pro (ERC1-C)
15m Waterproof Coaxial cable INCLUDED
Full HD (1920 x 1080) @30fps
2. Dimension
Length 70.4 mm (2.77″) x Width 56.6 mm (2.23″) x Height 36.1 mm (1.42″)
Weight: 0.35 lb / 157 g
3. Compatible Models
Compatible with the DR770X front cameras and DR770X Box recording box.
Front camera holder. The patented mounting system guarantees quick and easy assembly and at the same time a stable image. If necessary, the camera can be simply detached from the holder.
The BlackVue Mount Kits include both front and rear/interior camera mounts for all current BlackVue dash cams. Refer to the Compatibility Table further down this page for information about compatibility with past models. Mount Kits include two or more mounts depending on the model, an extra set of adhesive tape, five cable clips and a pry tool.
The BlackVue Mount Kits include both front and rear/interior camera mounts for all current BlackVue dash cams. Refer to the Compatibility Table further down this page for information about compatibility with past models. Mount Kits include two or more mounts depending on the model, an extra set of adhesive tape, five cable clips and a pry tool.
The BlackVue Mount Kits include both front and rear/interior camera mounts for all current BlackVue dash cams. Mount Kits include two or more mounts depending on the model, an extra set of adhesive tape, five cable clips and a pry tool.
The BlackVue Tape Kits include both front and rear/interior camera mount tape for all current BlackVue dash cams. Tape Kits include two sets of mounting tape for the corresponding dash cam model, five cable clips and a pry tool.
The BlackVue Tape Kits include both front and rear/interior camera mount tape for all current BlackVue dash cams. Tape Kits include two sets of mounting tape for the corresponding dash cam model, five cable clips and a pry tool.
The BlackVue Tape Kits include both front and rear/interior camera mount tape for all current BlackVue dash cams. Tape Kits include two sets of mounting tape for the corresponding dash cam model, five cable clips and a pry tool.
The BlackVue Tape Kits include both front and rear/interior camera mount tape for all current BlackVue dash cams. Tape Kits include two sets of mounting tape for the corresponding dash cam model, five cable clips and a pry tool.
The BlackVue Tape Kits include both front and rear/interior camera mount tape for all current BlackVue dash cams. Tape Kits include two sets of mounting tape for the corresponding dash cam model, five cable clips and a pry tool.
